I just made a laser guided blowgun for under $3, but don't let its simplicity fool you.

Acabei de fazer uma zarabatana guiada a laser por menos de US$ 3, mas não se deixe enganar pela simplicidade.

It's powerful enough to break glass, and even blast darts into concrete. In this project

É poderoso o suficiente para quebrar vidros e até mesmo atirar dardos em concreto. Neste projeto

we're making a custom laser sighted blowgun, that not only looks cool, but adds another

estamos fazendo uma zarabatana personalizada com mira laser, que não só parece legal, mas também adiciona outra

dimension to the fun you can have, in the backyard.

dimensão à diversão que você pode ter no quintal.

Let's start this project with a roll of scotch tape, a stack of sticky notes, and

Vamos começar este projeto com um rolo de fita adesiva, uma pilha de notas adesivas e

a paper party hat. I'm using the small 2x2 squares, and if we wrap one carefully around

um chapéu de festa de papel. Estou usando os pequenos quadrados 2x2, e se enrolarmos um cuidadosamente ao redor

the tip of the hat, the cone shape acts as a forming guide for making a pointy paper

a ponta do chapéu, o formato do cone atua como um guia de formação para fazer um papel pontudo

dart. We'll need a little bit of tape to reinforce the tip and hold it altogether,

dardo. Precisaremos de um pouco de fita para reforçar a ponta e mantê-la unida,

so when it slides off, it'll still keep its conical shape. Now watch what happens

então quando ele deslizar, ele ainda manterá seu formato cônico. Agora observe o que acontece

if we push the tip into a 1/2” PVC tube and give it a little twist. You can see the

se empurrarmos a ponta em um tubo de PVC de 1/2” e dermos uma pequena torção. Você pode ver o

pressure leaves a little mark right where it starts getting too big for the tube. Let's

a pressão deixa uma pequena marca bem onde começa a ficar grande demais para o tubo. Vamos

carefully trim along the inside edge of the marking, and just like that, we've made

corte cuidadosamente ao longo da borda interna da marcação e, assim, fizemos

a mini paper dart that'll fit perfectly inside the blowgun barrel. But it's not

um mini dardo de papel que vai caber perfeitamente dentro do cano da zarabatana. Mas não é

quite ready to use yet. We still need to add some weight to the tips so they'll fly straight.

bastante pronto para usar ainda. Ainda precisamos adicionar algum peso às pontas para que voem retos.

I found one of the quickest and easiest ways to do that, is to squirt a little hot glue

Descobri que uma das maneiras mais rápidas e fáceis de fazer isso é esguichar um pouco de cola quente

inside the cones until they're about 1/3rd of the way full. If you don't have hot glue,

dentro dos cones até que estejam cerca de 1/3 cheios. Se você não tiver cola quente,

try pulling off a little piece of poster putty instead, and shove it down into the tip with

tente puxar um pequeno pedaço de massa de pôster e empurre-o para baixo na ponta com

something like a screwdriver. That'll work just as good. Alright, we've got some paper

algo como uma chave de fenda. Isso vai funcionar tão bem. Tudo bem, temos um pouco de papel

darts. All we need now is a blowgun, so let's work on making that next. I went to the hardware

dardos. Tudo o que precisamos agora é de uma zarabatana, então vamos trabalhar nisso depois. Eu fui até o hardware

store and picked up a 2 foot length of 1/2” PVC pipe, and a reducing adaptor. This female

armazene e pegue um pedaço de 2 pés de tubo de PVC de 1/2” e um adaptador redutor. Esta fêmea

adaptor is 3/4” on one side, and reduces to a 1/2” slip connector on the other. Now

adaptador é 3/4” de um lado, e reduz para um conector deslizante de 1/2” do outro. Agora

if we simply push the adaptor onto the tube and give it a little tap, we've just created

se simplesmente empurrarmos o adaptador no tubo e dermos uma pequena batida, acabamos de criar

a super simple blowgun that can be used right away. You can see the weighted darts fly amazingly

uma zarabatana super simples que pode ser usada imediatamente. Você pode ver os dardos pesados voando incrivelmente

straight, and will take out paper cups with an impressive amount of power. They're just

reto, e vai tirar copos de papel com uma quantidade impressionante de poder. Eles são apenas

strong enough to do a little damage, but still safe enough to shoot around the house. Not

forte o suficiente para causar um pequeno dano, mas ainda seguro o suficiente para atirar pela casa. Não

that you should. But you could. Alright, let's take this system to a whole new level with

que você deveria. Mas você poderia. Tudo bem, vamos levar esse sistema para um nível totalmente novo com

a roll of duct tape, and some wire nails. I got this roll of camouflage tape from the

um rolo de fita adesiva e alguns pregos de arame. Eu peguei esse rolo de fita de camuflagem do

hardware store, and we'll need to start by putting a long strip on the table with

loja de ferragens, e precisaremos começar colocando uma longa tira na mesa com

the sticky side facing up. Now watch this. If we carefully set the pipe lengthwise in

o lado pegajoso voltado para cima. Agora observe isto. Se cuidadosamente colocarmos o tubo longitudinalmente em

the center of the tape, then gently rock it from side to side, the tape will start to

o centro da fita, então balance-a suavemente de um lado para o outro, a fita começará a

wrap itself around the tube. Doing the same thing with a second piece of tape will cover

enrolar-se em volta do tubo. Fazer a mesma coisa com um segundo pedaço de fita irá cobrir

any gaps, and just like that, our blowgun's got a custom camo wrap. Now just add some

quaisquer lacunas, e assim, nossa zarabatana tem um envoltório de camuflagem personalizado. Agora é só adicionar um pouco

electrical tape around the tip of the barrel and around the mouthpiece, to cover the rough

fita isolante ao redor da ponta do cano e ao redor do bocal, para cobrir a parte áspera

edges and make it look a little nicer. At this point, you can see our blowgun is starting

bordas e torná-lo um pouco mais bonito. Neste ponto, você pode ver que nossa zarabatana está começando

to look pretty serious. So let's get busy making some rounds of ammunition that are

para parecer bem sério. Então, vamos começar a fazer algumas rodadas de munição que são

a little more serious as well. I'm using #16 and #18 wire nails, because they're

um pouco mais sério também. Estou usando pregos de arame nº 16 e nº 18, porque eles são

relatively lightweight, and have a nice flat head on the top. You can see when a nail gets

relativamente leve e tem uma cabeça plana e bonita no topo. Você pode ver quando um prego fica

pushed through an empty paper cone, it instantly transforms into a high speed nail dart. It'll

empurrado através de um cone de papel vazio, ele se transforma instantaneamente em um dardo de prego de alta velocidade. Ele vai

work fine just like this, but to make it a little more durable, try adding a dab of hot

funciona bem assim, mas para torná-lo um pouco mais durável, tente adicionar um pouco de água quente

glue on the inside of the cone, then pulling down on the nail until the head catches firmly

cole na parte interna do cone e puxe o prego para baixo até que a cabeça fique firmemente presa

at the bottom. They'll need about 2 minutes for the glue to cool and harden, so while

na parte inferior. Eles precisarão de cerca de 2 minutos para a cola esfriar e endurecer, então, enquanto

we're waiting, why don't we try making something a little different. A stack of colored

estamos esperando, por que não tentamos fazer algo um pouco diferente? Uma pilha de cores

sticky notes will make different colored darts, and just for fun I snipped the tips off these

notas adesivas farão dardos de cores diferentes, e só por diversão cortei as pontas deles

purple ones and drove small screws deep into the glue. I call these ones my glass breakers,

roxos e enfiei pequenos parafusos profundamente na cola. Eu os chamo de meus quebra-vidros,

and you'll see how they got that name in just a minute. Now if you wanna experiment

e você verá como eles conseguiram esse nome em apenas um minuto. Agora se você quiser experimentar

with different types of darts, you can really use any length of nail you want. Smaller darts

com diferentes tipos de dardos, você pode realmente usar qualquer comprimento de unha que desejar. Dardos menores

will be easier to shoot, and fly faster, while heaver darts will penetrate deeper and do

será mais fácil de atirar e voar mais rápido, enquanto os dardos mais pesados penetrarão mais profundamente e farão

more damage. Now that we've got some good ammunition, we're gonna need a way to

mais danos. Agora que temos uma boa munição, vamos precisar de uma maneira de

store it. I found a 6” length of 1/2” foam pipe insulation for a little over a dollar,

guarde-o. Encontrei um pedaço de 6” de isolamento de tubo de espuma de 1/2” por pouco mais de um dólar,

and tried cutting little donut shapes off the end, about 3/4” thick. I used some electrical

e tentei cortar pequenas formas de donuts na ponta, com cerca de 3/4” de espessura. Usei um pouco de eletricidade

tape to reinforce the outside of the disc, then just for looks, used a black marker to

fita para reforçar a parte externa do disco, então só para dar uma aparência, usei um marcador preto para

color the foam a little bit darker. The next step is to make another foam disc the exact

colorir a espuma um pouco mais escura. O próximo passo é fazer outro disco de espuma exatamente

same way, then slide both of them onto the barrel of the blowgun. At this point, we're

da mesma forma, então deslize os dois no cano da zarabatana. Neste ponto, estamos

ready to modify the quiver so it'll carry 8 rounds of ammunition. I found a phillips

pronto para modificar a aljava para que ela carregue 8 cartuchos de munição. Eu encontrei uma Phillips

head screwdriver and carefully heated it over a flame for about 20 seconds. That get's

chave de fenda e cuidadosamente aquecida sobre uma chama por cerca de 20 segundos. Isso fica

it just hot enough to burn little holes into the foam on contact. Just make sure you're

está quente o suficiente para queimar pequenos furos na espuma em contato. Apenas certifique-se de que você está

only burning holes in the top disc because we're gonna want the bottom one left

queimando apenas buracos no disco de cima porque vamos querer o de baixo sobrando

intact. You can see the 8 holes we made space the darts evenly, and guide the nails as they

intacto. Você pode ver os 8 furos que fizemos espaçando os dardos uniformemente e guiando os pregos conforme eles

push down into the padding below. These makeshift quivers keep all the darts securely in place,

empurre para baixo no acolchoamento abaixo. Essas aljavas improvisadas mantêm todos os dardos firmemente no lugar,

while protecting the tips of the darts at the same time. Alright, our customized blowgun

enquanto protege as pontas dos dardos ao mesmo tempo. Tudo bem, nossa zarabatana personalizada

is looking pretty impressive, and we could stop here. But let's go one step further,

está parecendo bem impressionante, e poderíamos parar por aqui. Mas vamos um passo além,

and give it a laser. I picked up a red laser pointer from the dollar store and hot glued

e apliquei um laser. Peguei um apontador laser vermelho na loja de um dólar e colei com cola quente

it 8-1/2” back from the tip of the barrel, then reinforced it with a couple of zip ties,

8-1/2” para trás da ponta do cano, então reforçado com um par de braçadeiras de plástico,

for durability. The thing I like best about these $1 lasers are how one button operates

para durabilidade. O que mais gosto nesses lasers de US$ 1 é como um botão opera

an LED flashlight, while the other activates the laser sight, making this system operable

uma lanterna LED, enquanto a outra ativa a mira laser, tornando este sistema operável

in the dark. Now I got a slightly better laser from the pet section of the grocery store

no escuro. Agora eu consegui um laser um pouco melhor na seção de animais de estimação do supermercado

and turned it into a custom laser scope that compliments the gun really well. With this

e o transformou em uma mira laser personalizada que complementa muito bem a arma. Com isso

setup, the position of the laser can be fine tuned with amazing precision, which you can

configuração, a posição do laser pode ser ajustada com precisão incrível, o que você pode

see, results in surprisingly accurate shots. Alright, now that we've got a custom, laser

veja, resulta em tiros surpreendentemente precisos. Tudo bem, agora que temos um laser personalizado

guided blowgun, let's have some fun. I took mine outside and found that the darts easily

zarabatana guiada, vamos nos divertir. Levei a minha para fora e descobri que os dardos disparam facilmente

penetrate into wooden posts with out even trying. They'll also stick into tree trunks,

penetram em postes de madeira sem nem tentar. Eles também grudam em troncos de árvores,

or completely abuse the side of a wooden deck, like the one on my kids playhouse. I was able

ou abusar completamente da lateral de um deck de madeira, como o da casa de brinquedo dos meus filhos. Eu era capaz

to hit some targets from over 100 feet away, and if I missed, the darts just sailed right

para atingir alguns alvos a mais de 30 metros de distância e, se eu errasse, os dardos simplesmente voavam para a direita

into the concrete wall behind it, which actually blows my mind completely. I still don't

na parede de concreto atrás dele, o que realmente me deixa completamente perplexo. Eu ainda não

really know how these stick into cinderblock, but they do. For one last experiment, I tried

realmente sei como eles grudam em blocos de concreto, mas eles grudam. Para um último experimento, tentei

loading one of the glass breaker rounds, and fired at a glass full of water. Needless to

carregando uma das balas de quebra-vidros e atirou em um copo cheio de água. Desnecessário dizer

say, they do live up to their name. Now you've probably realized that if you use different

digamos, eles fazem jus ao seu nome. Agora você provavelmente percebeu que se você usar diferentes

rolls of tape, you can customize your blowgun any way you want, and if you want a safer

rolos de fita, você pode personalizar sua zarabatana da maneira que quiser e, se quiser uma mais segura

kind of ammo, try using colored mini marshmallows. They're the perfect fit for 1/2” PVC,

tipo de munição, tente usar mini marshmallows coloridos. Eles são perfeitos para PVC de 1/2”,

and can be shot safely, but still with incredible accuracy. Well now you know how to make an

e pode ser disparado com segurança, mas ainda com precisão incrível. Bem, agora você sabe como fazer um

incredible, laser guided blowgun, that will rattle off nail darts with power and precision.

incrível zarabatana guiada a laser que dispara dardos de pregos com potência e precisão.

The best part is, if you make these in bulk, they can cost as little as $2.50 each. And

A melhor parte é que, se você fizer isso em grandes quantidades, eles podem custar apenas US$ 2,50 cada. E

that's including the $1 laser. Well that's it for now. If you liked this project perhaps

isso inclui o laser de $1. Bem, é isso por enquanto. Se você gostou deste projeto, talvez

you'll like some of my others. Check them out at www.thekingofrandom.com

você vai gostar de alguns dos meus outros. Confira-os em www.thekingofrandom.com

Expandir Legenda

Divirta-se e Aprenda Inglês com: Como Fazer Uma Pistola De Ar Comprimido Assistida Por Laser. Tradução com Legendas em Inglês e Português.

Vídeos Relacionados
